System energy:14.50kWh
Material:three-element composite
cell:10Ah NCM
Standard charging:0.2C,6~8hour
Nominal voltage:366.3V
Quick charging:3C,around 20 minutes
1. Customization:to provide customizatiation services on exploiting battery box and make sure that entire vehicle owns optimization of general layout
2. Higher level of security and protection: design of multiple security and protection and make sure that entire vehicle works safely and be operated reliably
3. Longer endurance mileage: increases endurance mileage of entire vehicle effectively with cell of high energy density and lightweight structural design High energy style pouch forming for NCM lithium-ion battery is so high on energy density sector165WH/KG
4.Longer life cycle:meets this requirement for life circle of the battery,such as 8 years or 120000 kilometers.The calendar life of battery system would be up to 8 years, and calendar life of signal cell would be more than 10 years in normal temperature,mechanical design of battery box meets the standard ISO/DIS 12405-3:2013
5. Perfect adaptability to environment: IP67 protection and waterproof,work perfectly in hign and cold regions and even the temperature is around -20℃
366V40Ah | Model:Plug-in hybrid electric vehicle | ||
system energy | 14.50kWh | material | three-element composite |
cell | 10Ah NCM | standard charging | 0.2C,6~8hour |
Nominal voltage | 366.3V | quick charging | 3C,approximately 20 minutes |
Operating temperature range | -20~55℃ | max discharge rate | 5C /6C,30s |
Protection level | IP67 | Communication interface | CAN |
Weight | 160kg | System component | Single box |
Working voltage range | 294V~411.6V | Serial and parallel structure | 4P99S |
